    PP or PVDF reinforced hollow fiber membrane mbr package plant wastewater treatment systems

    Ask Lasest Price
    Brand Name : CHENENG
    Model Number : CRS
    Certification : CE/ISO
    Price : negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 10pcs per month
    Delivery Time : 30 working days after received your payment
    • Product Details
    • Company Profile

    PP or PVDF reinforced hollow fiber membrane mbr package plant wastewater treatment systems


    The advantage of CHENENG MBR system for you
    PP or PVDF or mPA reinfroced hollow fiber membrane
    Anti-fouling,bigger flux,super hydriphilic
    Capacities from 10 to 100 000 m3/day
    Standard pre-engineered design packages
    Efficient, compact design, reduced footprint
    Robust, high-quality system and components
    Single-source supply,Easily expandable
    Fast delivery and installation,modular design
    Meets or exceeds most regulatory requirements

    Range of MBR applications

    MBR plants are increasingly uesd for locations where water resources are scarce,reusable-
    quality effluent is desirable,space availability is limited,and/or stringent discharge standands are in effect.There locations includes small communities,housing developments,commerialdevelopments,
    mining camps,resorts,hotels,malls,schools,and golf courses,among others.What's more,the MBR system
    has been employed in industrail waste water processing and recycle,desalination prefilter,municipal water treatment,the factory of chemical or pesticide or cosmetic or pharmaceuticals ,etc.


    Specifications

    Type

    size

    Treatment

    capacity

    Membrane

    size

    Qty

    (pcs)

    Module

    (units)

    Total

    Installed power

    Operating power

    (KW)

    Tank size(mm)

    No.s of tank

    CRS-25

    25 m³/d

    PURE-100

    80

    1

    7.8

    3.35

    9000*2400*2500

    1

    CRS-40

    40 m³/d

    PURE-100

    100

    1

    7.8

    3.35

    7000*2400*2500

    1

    CRS-50

    50 m³/d

    PURE-100

    160

    2

    9.75

    5.25

    9000*2400*2500

    1

    CRS-80

    80 m³/d

    PURE-100

    200

    2

    13.8

    5.25

    10000*2400*2500

    1

    CRS-100

    100 m³/d

    PURE-100

    140

    3

    19.9

    10.7

    10000*2400*2500

    1

    CRS-120

    120 m³/d

    PURE-100

    300

    3

    21.75

    13.55

    10000*2400*2500

    1

    CRS-160

    160 m³/d

    PURE-100

    400

    4

    27.75

    16.55

    12000*2400*2500

    1

    CRS-200

    200 m³/d

    PURE-100

    500

    5

    30.85

    18.25

    7000*2400*2500

    2

    CRS-240

    240 m³/d

    PURE-100

    600

    6

    38.9

    23.2

    8500*2400*2500

    2

    CRS-320

    320 m³/d

    PURE-100

    800

    8

    38.9

    23.2

    10000*2400*2500

    2

    CRS-400

    400 m³/d

    PURE-100

    1000

    10

    30.35

    15.75

    11500*2400*2500

    2

    CRS-480

    480 m³/d

    PURE-100

    1200

    12

    33.65

    15.9

    13500*2400*2500

    12000*2400*2500

    1

    1

    CRS-560

    560 m³/d

    PURE-100

    1400

    14

    43.85

    21

    8500*2400*2500

    3

    CRS-640

    640 m³/d

    PURE-100

    1600

    16

    41.85

    20

    11500*2400*2500

    3

    CRS-720

    720 m³/d

    PURE-100

    1800

    18

    54.85

    26

    12000*2400*2500

    3
